Install The Server (4-Post, 600-Mm Hardmount Kit) - Oracle Netra Server X3-2 Installation Manual

600-mm, 4-Post Hardmount Screws
TABLE:
Quantity Description
12 M5 x 7 SEM screws
10 M5 x 12.7 mm screws
10 M6 x 13 mm screws
9 M6 square clip nuts
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws
Related Information
"Install the Server (4-Post, 600-mm Hardmount Kit)" on page 42
■
"Tools Needed for Installation" on page 22
■
"Handling Precautions" on page 20
■
"Rack Cautions" on page 23
■
▼ Install the Server (4-Post, 600-mm Hardmount
Kit)
Note – The front-to-back rail spacing must be at least 15.43 in. (392 mm) and not
more than 19.84 in. (504 mm) from the outside face of the front rail to the outside face
of the back rail.
1. Gather the required tools.
See
2. Read the server cautions.
See
3. Read the rack cautions and stabilize the rack.
See
4. Get the adjustable rails from the rack kit.
See
42 Netra Server X3-2 Installation Guide • May 2013
"Tools Needed for Installation" on page
"Handling Precautions" on page 20
"Rack Cautions" on page 23
"600-mm Hardmount Kit (4-Post Rack)" on page
Where Used
8 for side rails, 4 for rear flanges
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
22.
and "ESD Precautions" on page
and "Stabilize the Rack" on page
41.
21.
24.
