Cable The Sp; Cable The Ethernet Ports - Oracle Netra Server X3-2 Installation Manual

▼ Cable the SP

●
Determine which of these SP connections works in your environment and
establish the connection:
SER MGT port
■
NET MGT port
■
VGA video and USB keyboard and mouse
■
You can configure any combination of these SP connections. See
Connections" on page
Note – The VGA video port is for temporary use during installation or service
procedures and has a maximum cable length limit of 6 meters.
Related Information
"Available Connections" on page 78
■
"Cable the Ethernet Ports" on page 81
■
"(Optional) Connect Other Data Cables" on page 82
■
"Identifying Ports" on page 82
■
"Rear Panel Components (Installation)" on page 7
■

▼ Cable the Ethernet Ports

Once the server is running the OS, these connections provide Ethernet access to the
server. See "Gigabit Ethernet Ports" on page
Note – The Oracle ILOM sideband management feature enables you to access the SP
using one of these Ethernet ports. Refer to the Server Administration for instructions.
1. Connect a Category 6 (or better) cable from your network switch or hub to
Ethernet Port 0 (NET0) on the rear of the chassis.
2. (Optional) Connect Category 6 (or better) cables from your network switch or
hub to the remaining Ethernet ports.
Related Information
"Available Connections" on page 78
■
"Cable the SP" on page 81
■
"(Optional) Connect Other Data Cables" on page 82
■
78.
84.
"Available
Connecting Cables 81
