Oracle Netra Server X3-2 Installation Manual page 12

Component
Service processor
Alarm connectors
Ethernet ports
PCIe slots
USB2.0 ports
Indicators and switches
Power supplies
Cooling
Related Information
"Installation Task Overview" on page 2
■
"Front Panel Components (Installation)" on page 5
■
"Rear Panel Components (Installation)" on page 7
■
Server Service
■
4 Netra Server X3-2 Installation Guide • May 2013
Description
Internal AST2300 SP, providing IPMI 2.0 compliant remote management
capabilities. The SP features:
• Oracle ILOM 3.1
• 2D graphics (HD-15 VGA Connector)
• Serial management (RJ-45)
• Network management (10/100BASE-T Ethernet RJ-45)
• Complete host remote management, including remote KVMS over Ethernet
Four Telco dry contact (electrically isolated) user alarms.
Four 10Gb/s Ethernet ports with integrated link/speed LEDs. Supports 100 Mb/s,
1000 Mb/sec, 10000 Mb/sec transfer rates.
Six PCIe Gen3 slots with x8 electrical interface that accommodate low-profile PCIe
cards.
6 ports (2 front, 2 rear, 2 internal).
Note - 1 internal USB port is preinstalled with a USB drive containing OSA.
• Power button switch
• Locate button switch with integrated LED
• System OK LED
• System Fault LED
• Alarm LEDs - Critical, Major, Minor, and User
• SP LED
• Rear PS LED
Depending on the model, one of the following configurations:
• 2 hot-swappable AC supplies (maximum 760 W)
• 2 hot-swappable DC supplies (maximum 660 W)
5 internal fans and one integrated power supply fan in each supply.
