Install The Server (4-Post, 19-Inch Sliding Rail Kit) - Oracle Netra Server X3-2 Installation Manual

TABLE:
No.
4
5
6
19-Inch Sliding-Rail Screws
TABLE:
Quantity Description
10 M4 x 0.5 mm x 5 mm Phillips panhead screws
10 M6 brass collar screws
8 M5 panhead screws, nuts, plain washers and
star washers
10 M5 x 12.7 mm screws
12 M6 x 13 mm screws
9 M6 square clip nuts
10 10–32 collar screws 4 short, 4 long, 2 extra
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws
Related Information
"Install the Server (4-Post, 19-Inch Sliding Rail Kit)" on page 34
■
"Tools Needed for Installation" on page 22
■
"Handling Precautions" on page 20
■
"Rack Cautions" on page 23
■
▼ Install the Server (4-Post, 19-Inch Sliding Rail
Kit)
Note – The front-to-back rail spacing must be at least 15.43 in.(392 mm) and not
more than 34 in. (863.6 mm) from the outside face of the front rail to the outside face
of the back rail.
34 Netra Server X3-2 Installation Guide • May 2013
19-Inch Sliding-Rail Kit Contents
Description
Screws
Telco slide assemblies (2)
Long brackets (2)
Where Used
8 for glides, 2 extra
4 for short brackets, 4 for long brackets, 2 extra
8 for slides
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
8 for racks with 10 to 32 holes, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
