There is no direct correspondence between the physical numbers of the slots on
the I/O backplane and the logical slot identification reported with the SRM con-
sole show config command (described in Chapter 2). Table 1–4 maps the
physical slot numbers to the SRM logical ID numbers.
See Chapter 4 for instructions on installing PCI options.
Table 1–4 How Physical I/O Slots Map to Logical Slots: Model 3B
Physical Slot
1 Hose 2 Slot ID 1
2 Hose 2 Slot ID 2
3 Hose 0 Slot ID 11
4 Hose 3 Slot ID 2
5 Hose 3 Slot ID 1
6 Hose 0 Slot ID 10
7 Hose 1 Slot ID 2
8 Hose 1 Slot ID 1
9
Hose 0 Slot ID 9
10 Hose 0 Slot ID 8
SRM Logical ID (10-Slot Legacy PCI)
System Overview 1-19
