10 Gigabit Ethernet technology for industry-
standard servers
Technology brief, 2
nd
Abstract .............................................................................................................................................. 2
Introduction ......................................................................................................................................... 2
Why 10GbE technology is important ..................................................................................................... 2
Current network architecture ................................................................................................................. 2
Types of data .................................................................................................................................. 2
Network and interconnect types ......................................................................................................... 3
10GbE networks.................................................................................................................................. 4
Full duplex operation ........................................................................................................................ 4
Latency ........................................................................................................................................... 5
HP supported 10GbE media standards ............................................................................................... 5
Converged network fabrics with 10GbE ................................................................................................. 6
iSCSI .............................................................................................................................................. 7
Fibre Channel over Ethernet .............................................................................................................. 8
HP approach to10GbE implementation .................................................................................................. 9
HP Dual Port 10GbE Server Adapters ................................................................................................. 9
Virtualization and Virtual Connect .................................................................................................... 10
Summary .......................................................................................................................................... 13
Appendix: Glossary .......................................................................................................................... 14
For more information .......................................................................................................................... 16
Call to action .................................................................................................................................... 16
edition
Small Computer System Interface .................................................................................................... 3
Ethernet ....................................................................................................................................... 4
Fibre Channel .............................................................................................................................. 4
InfiniBand .................................................................................................................................... 4
Physical medium dependent connections for 10GbE ......................................................................... 5
Transceiver modules ..................................................................................................................... 6
10GbE connection standards ......................................................................................................... 6
Server Virtualization ................................................................................................................... 10
NIC virtualization ....................................................................................................................... 10
Flex-10 for Virtual Connect .......................................................................................................... 10
Advertisement
Table of Contents
Related Manuals for Compaq BL10e - HP ProLiant - 512 MB RAM
Summary of Contents for Compaq BL10e - HP ProLiant - 512 MB RAM
-
Page 1: Table Of Contents
10 Gigabit Ethernet technology for industry- standard servers Technology brief, 2 edition Abstract .............................. 2 Introduction ............................2 Why 10GbE technology is important ..................... 2 Current network architecture ......................... 2 Types of data ..........................2 Network and interconnect types ......................3 Small Computer System Interface .................... -
Page 2: Abstract
Abstract This paper examines 10 Gigabit Ethernet (10GbE) technology as the network architecture of choice to address requirements for increased bandwidth and reduced latency. 10GbE also provides broader opportunities for network redundancy in data center environments and other situations where these properties are essential. -
Page 3: Network And Interconnect Types
Clustering – Inter-Process Communication (IPC) data is a method for exchanging data among two or more threads in one or more compute nodes. HPC Cluster computing is a typical example using IPC. IPC is employed mostly for passing instructions and redistributing large amounts of data between shared, distributed applications. -
Page 4: Ethernet
(iSCSI) is a standard that implements the SCSI protocol over IP networks to enable connectivity with storage devices. The self-titled section later in this paper provides more details about iSCSI. Ethernet Ethernet is the most well-established of the interconnects and is utilized for IP-based communications such as email, web browsing, management, Voice Over Internet Protocol (VOIP), VOD, and iSCSI. -
Page 5: Latency
Latency Transmission latency within networks typically has three components – time of flight, data rate, and queuing or buffer delays. Time of flight is the propagation delay across the cable, and that delay increases in a linear fashion with distance. The data rate affects how long a packet takes to complete transmission, from first bit sent to last bit received. -
Page 6: Transceiver Modules
The typical 10GbE LAN optical standards can be summarized as follows: 10GBASE-LR (10km over single-mode) 10GBASE-SR (26m – 300m over multi-mode) 10GBASE-LRM (220m over multi-mode) Transceiver modules 10 GbE ports on switches and routers are typically independent and can be installed with pluggable transceiver modules making it convenient for end users to change media and distance ranges. -
Page 7: Iscsi
using a single switching technology and a single set of adapters that meet the requirements of all four types of data: LAN, IPC, management, and storage. Figure 2. Transition from multiple networks to a converged network Multiple Data Networks Converged Data Network Processor Processor Processor... -
Page 8: Fibre Channel Over Ethernet
iSCSI protocol, such as a tape drive. The iSCSI stack at both ends of the path is used to encapsulate SCSI block commands into Ethernet Packets for transmission over IP networks as illustrated in Figure 3. Figure 3. iSCSI is SCSI over TCP/IP iSCSI initiator File System File System... -
Page 9: Hp Approach To10Gbe Implementation
HP approach to10GbE implementation As 10GbE technology becomes more prominent in the marketplace, HP expects 10GbE network components to fulfill needs of applications that benefit from 10GbE bandwidth. HP offers a broad portfolio of 10GbE products for ProLiant blade, rack, and tower platforms. HP 10GbE architecture includes network designs that are optimized for speed, reliability, and redundancy. -
Page 10: Virtualization And Virtual Connect
The NC524SFP PCI Express version 2 adapter, shown in Figure 5, ships with two SFP+ cages suitable for connecting to DAC or fiber modules supporting SR, LR, and LRM fiber optic cabling. The NC524SFP allows customers to provision their HP ProLiant DL370 G6 and ProLiant ML370 G6 servers with 10Gb bandwidth. - Page 11 partition by setting it to a user-defined portion of the total 10Gb connection. Speed can be set from 100 Megabits per second to 10 Gigabits per second in 100 Megabit increments. There are advantages to partitioning a 10 GbE pipeline: More NIC connections per server, which is especially important in a virtual machine environment.
- Page 12 Figure 7. HP VC Flex-10 10Gb Ethernet Module Recessed module reset button 1x 10GBASE-CX4 Ethernet or 2x Crosslinks (midplane) or 5x SFP+ modules (X2-6) 1x SFP+ module (X1) 2x SFP+ module (X7-8) (1GbE or 10GbE) Port Number & Status Indicators Indicates whether a data center link (green), stacking link (amber), or highlighted port (blue).
-
Page 13: Summary
Flex-10 allows the traffic of four FlexNICs to share the same high performance 10GbE port on the signal midplane yet keep the data entirely separated. A special VLAN tag is attached to the packet being sent and that tag gets stripped off at the destination. Packets that have been tagged and isolated by VC and the FlexNICs then move from the Flex-10 device (LOM or mezzanine card) to the Flex-10 VC Enet module on a single pathway. -
Page 14: Appendix: Glossary
Appendix: Glossary 802.3ae – The IEEE standard for 10 Gigabit Ethernet over fiber 802.3ak – The IEEE standard for over coaxial cable 10 Gigabit 802.3an – The IEEE standard for 10GBASE-T copper twisted pair 802.3ab – The IEEE standard for UTP Gigabit Ethernet (1000BASE-T) 802.3z –... - Page 15 Multiple Switched Fabrics – In the Fibre Channel switched fabric topology (called FC-SW), devices are connected to each other through one or more Fibre Channel switches. Multiple switches in a fabric usually form a mesh network, with devices being on the "edges" of the mesh. OSI –...
-
Page 16: For More Information
For more information For additional information, refer to the resources listed below. Resource description Web address http://h71028.www7.hp.com/ERC/downloads/4AA0- 10 Gigabit Ethernet: meeting the needs of 8078ENW.pdf the next generation data center http://www.hp.com/go/ProLiantNICs HP ProLiant networking 10GbE network adapters HP BladeSystem 10GbE Interconnects http://h18004.www1.hp.com/products/blades/components/c- class-interconnects.html http://h18004.www1.hp.com/products/servers/proliant-...
