Table 4–1 Disk Drive Status LED Conditions
LED is on
This display at initial startup may mean:
The operational drive is not being accessed.
The drive status is one of the following:
•
The drive is a replacement drive to be rebuilt.
•
The drive is an inactive spare disk.
•
The drive is spinning up during POST.
•
The SCSI controller cannot control the LED
If the display does not change within a few minutes, the drive is
non-operational.
The operational drive is not being accessed.
Drive is being rebuilt or array capacity expansion is in progress.
The operational drive is not being accessed.
The drive is configured as part of an array.
Drive selected using the Array Configuration Utility.
The drive locate function is active.
The drive is operational and active.
The drive is configured as part of an array.
4-42 ES45 Owner's Guide
LED is off LED is flashing
