Front Panel

Removing
1. With the front bezel removed and the ribbon cable disconnected
from the front panel, remove the circlip from the top hinge of the
removable media drive bay door (which should be closed and
locked).
Figure 4-14 Removing the circlip
1. Circlip
S e r v i c e I n f o r m a t i o n
2
1
2. Top Hinge of Drive Bay Door
OWNER'S HANDBOOK 4-15
