10. Define the
subscriber (in Kbps).
Define the
11.
subscriber (in Kbps).
Enter the
12. Maximum users per group
Select a policy from the
13.
page 120 for more information.
14. Enable STMP Redirection
redirected by the global SMTP redirect configuration.
Click on the
Add
you want to reset all the values to their previous state.

Displaying Current Subscriber Connections {Current}

You can display a listing of all the subscribers currently connected to the system. The list
includes the MAC addresses of the subscribers, their active state, the individual expiration
times, port numbers (if assigned), bandwidth limits, current bandwidth usage, and the number
of bytes that have been passed from the subscriber to the Internet. This data can be used if a
dispute arises between the subscriber and the solution provider (for example, if a subscriber
claims that their connection to the Internet was not completed). By reviewing the "byte"
statistics, you can clearly see if the subscriber made a successful connection.
To view the list of Current Subscriber Connections, go to the Web Management Interface,
click on
Subscriber Administration
System Administration
Min Upstream Bandwidth
Min Downstream Bandwidth
QoS Policy
to allow the specified user to have their SMTP traffic
button to add this subscriber to the database, or click on the
and Max Upstream Bandwidth
and
Max Downstream Bandwidth
for the subscriber account.
menu. See "Setting up Quality of Service {QoS}" on
, then click on
Current.
range for this
range for this
button if
Reset
179
