Nomadix Access Gateway User Manual page 117

A G
CCESS ATEWAY
Subscriber Tracking Log
Enabling this checkbox enables the Subscriber Tracking log. Use this to track the network
usage of specific Subscribers on the network by receiving a syslog of every Session that is
opened by each subscriber. Each new DAT session that is created for subscribers is logged
in these syslogs. Proxy state, type of access, and Username are included besides the source
and destination information of each session. There are IN and OUT messages for the
beginning and ending of each session.
Examples:
INFO [Access Gateway v2.4.113] LI : IN-->: THU JUN 23 11:43:58 2007 | testlab |
S(192.168.2.4/3444), D(66.163.175.128/80), X(67.130.149.4/5004), non-proxy ,
00:90:27:78:81:00, RADIUS, IPASS/0U0000
INFO [Access Gateway v2.4.113] LI : OUT-->: THU JUN 23 11:44:01 2007 | testlab |
S(192.168.2.4/3444), D(66.163.175.128/80), X(67.130.149.4/5004), non-proxy ,
00:90:27:78:81:00, RADIUS, IPASS/0U0000
Field formats explained:
LI : IN-->: Day Month Date Time Year | NSE_Site_Name | S(Source_IP/Port),
D(Destination_IP/Port), X(NSE_Translated_IP/Port), proxy_type , Subscriber_MAC,
Billing_Type, UserName(first 12 char). LI : IN-->: THU JUN 23 11:43:58 2007 | testlab |
S(192.168.2.4/3444), D(66.163.175.128/80), (67.130.149.4/5004), non-proxy ,
00:90:27:78:81:00, RADIUS, IPASS/0U0000
Do not configure the Server IP as the Network side IP of the gateway Stored
syslogs are viewable under System/Syslog menu. A total of 500 syslogs are
stored locally.
System Administration 105
