In Room Port Mapping
This section shows In Room Port Mapping from the subscriber side, when the In Room Port
Mapping feature is enabled.
Access Gateway multiple VLAN tagged systems can use the same tags and be
placed on different Subscriber ports. Although it is technically possible to place
two different VLAN tagged switches (one on each Subscriber side) that have the
same VLAN tags designated, this configuration can cause problems. To avoid
conflicts, you must ensure that the VLAN tags are different on the different
devices.
Enable
1. In Room Port Mapping
section, Steps 2 and 3).
Enter the following URL target format:
2.
http://(Access Gateway IP address):1111/usg/roommapping
For example:
http://219.57.108.103:1111/usg/roommapping
The Enter Network Password prompt appears:
Click here if you want to save your
user name and password
118
and assign a user name and password (see previous
A G
CCESS ATEWAY
Enter user name and
password
