xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Audio Channels

Shows the number of incoming audio channels.
Value space of the result returned:
<Integer value>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Audio Channels
*s MediaChannels Call 27 IncomingAudioChannel 327 Audio Channels: 1
** end
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTP Local
IpAddress
Shows the local IP address of the Real-time Transport Protocol (RTP) port for the incoming audio in
the media channel.
Value space of the result returned:
<S: 0, 255>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Local
IpAddress
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Local
IpAddress: "192.168.24.190"
** end
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTP Local Port
Shows the local UDP port number of the Real-time Transport Protocol (RTP) port for the incoming
audio in the media channel.
Value space of the result returned:
<1..n>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Local
Port
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Local Port:
16404
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTP Remote
IpAddress
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTP Remote
Port
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTCP Local
IpAddress
133
xCommand
Shows the remote IP address of the Real-time Transport Protocol (RTP) port for the incoming audio in
the media channel.
Value space of the result returned:
<S: 0, 255>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Remote
IpAddress
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Remote
IpAddress: "192.168.136.130"
** end
Shows the remote UDP port number of the Real-time Transport Protocol (RTP) port for the incoming
audio in the media channel.
Value space of the result returned:
<1..n>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Remote
Port
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTP Remote Port:
50932
** end
Shows the local IP address of the Real-time Transport Control Protocol (RTCP) port for the incoming
audio in the media channel.
Value space of the result returned:
<S: 0, 255>
Example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local
IpAddress
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local
IpAddress: "192.168.24.190"
** end
