xConfiguration Experimental BrightnessGradient Camera [1..7] Level

NOTE: The Experimental settings can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
NOTE: Applies to Cisco TelePresence T1/T3. This settings can be configured from the command
line interface, and not from the menu. Set the camera brightness gradient level to control the row
dependent digital gain for the top row of the image. The gain gradient is applied so that intermediate
rows have gains that are determined by linear interpolation of the top row gain and the gain for the
bottom row. A gain of 1.0x is always applied to the bottom row of the image.
Requires user role: ADMIN
Value space: <10..39>
Range: The range 10 to 39 corresponds to gains in the range 1.0x to 3.9x.
Example: xConfiguration Experimental BrightnessGradient Camera 1 Level: 10

xConfiguration Experimental CapsetFilter

NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
ADMIN
Requires user role:
<S: 0, 100>
Value space:
Example: xConfiguration Experimental CapsetFilter: ""

xConfiguration Experimental CapsetReduction

NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
<Auto/Reduced>
Value space:
xConfiguration Experimental CapsetReduction: Auto
Example:

xConfiguration Experimental Conference [1..1] PacketLossResilience

ForwardErrorCorrection
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Will enable ForwardErrorCorrection (RFC5109) mechanism as part of the PacketLossResilience
mechanism. Default value is On.
On: Forward error correction will be used as part of the PacketLossResilience mechanism.
Off: Forward error correction will NOT be used as part of the PacketLossResilience mechanism.
Requires user role: ADMIN
Value space: <On/Off>
Example: xConfiguration Experimental Conference 1 PacketLossResilience
ForwardErrorCorrection: On
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration Experimental Conference [1..1] PacketLossResilience RateAdaption
xConfiguration Experimental Conference [1..1] ReceiverBasedDownspeeding

xConfiguration Experimental CustomSoftbuttons HoldResume

67
xCommand
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Will use the a RateAdaption algorithm adapted to the PacketLossResilience mechanism. Default value
is On.
Requires user role: ADMIN
Value space: <On/Off>
On: RateAdaption will be used as part of the PacketLossResilience mechanism.
Off: RateAdaption will NOT be used as part of the PacketLossResilience mechanism.
xConfiguration Experimental Conference 1 PacketLossResilience
Example:
RateAdaption: On
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <On/Off>
Example: xConfiguration Experimental Conference 1 ReceiverBasedDownspeeding:
Off
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
This configuration is used to enable Call Hold and Resume in the OSD. Note that Call Hold and
Resume will be available even if this setting is set to Off, if Multiway is configured.
ADMIN
Requires user role:
<Off/On>
Value space:
Off: Call Hold and Resume is not available (unless Multiway is configured).
On: Call Hold/Resume is available while the system is in a call. It will be available on softbuttons,
and when receiving incoming calls the user will have the option of holding any current calls while
accepting the new call.
xConfiguration Experimental CustomSoftbuttons HoldResume: Off
Example:
