The Diagnostics status
xStatus Diagnostics
Shows the top level overview of the diagnostics. The example shows the status for an ongoing call.
The identities of the call and channels are used when querying additional information.
Example:
xStatus Diagnostics
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1 Jitter: 0
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1 Packets:
132505
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1
LastIntervalLost: 0
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1
LastIntervalReceived: 84
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1 Bytes:
21200960
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1
ChannelRate: 64000
*s Diagnostics Call 27 Channels IncomingAudioChannel 327 Netstat 1
MaxJitter: 0
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1 Jitter: 6
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1 Packets:
133166
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1
LastIntervalLost: 0
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1
LastIntervalReceived: 148
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1 Bytes:
122301901
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1
ChannelRate: 506000
*s Diagnostics Call 27 Channels IncomingVideoChannel 330 Netstat 1
MaxJitter: 9
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 Jitter: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 Packets: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1
LastIntervalLost: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration
124
xCommand
LastIntervalReceived: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 Bytes: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1
ChannelRate: 0
*s Diagnostics Call 27 Channels IncomingDataChannel 335 Netstat 1 MaxJitter:
0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1 Jitter: 0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1 Packets:
0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1 Bytes: 0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1
ChannelRate: 0
*s Diagnostics Call 27 Channels OutgoingAudioChannel 328 Netstat 1
MaxJitter: 0
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1 Jitter: 4
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1 Packets:
123043
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1 Bytes:
94720991
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1
ChannelRate: 493000
*s Diagnostics Call 27 Channels OutgoingVideoChannel 331 Netstat 1
MaxJitter: 4
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 Jitter: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 Packets: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 Loss: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 Drop: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 Bytes: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1
ChannelRate: 0
*s Diagnostics Call 27 Channels OutgoingDataChannel 336 Netstat 1 MaxJitter:
0
** end
