The Phonebook configuration

xConfiguration Phonebook Server [1..1] ID
Enter a name for the external phonebook.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
xConfiguration Phonebook Server 1 ID: ""
Example:
xConfiguration Phonebook Server [1..1] Type
Select the phonebook server type.
Requires user role: ADMIN
Value space: <VCS/TMS/Callway/CUCM>
VCS: Select VCS if the phonebook is located on the Cisco TelePresence Video Communication
Server.
TMS: Select TMS if the phonebook is located on the Cisco TelePresence Management Suite
server.
Callway: Select Callway if the phonebook is to be provided by the Callway subscription service.
Contact your Callway provider for more information.
CUCM: Select CUCM if the phonebook is located on the Cisco Unified Communications Manager.
Example: xConfiguration Phonebook Server 1 Type: TMS
xConfiguration Phonebook Server [1..1] URL
Enter the address (URL) to the external phonebook server.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
xConfiguration Phonebook Server 1 URL: "http://tms.company.com/tms/
Example:
public/external/phonebook/phonebookservice.asmx"
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

The Provisioning configuration

xConfiguration Provisioning Connectivity

xConfiguration Provisioning Mode

xConfiguration Provisioning LoginName

49
xCommand
This setting controls how the device discovers whether it should request an internal or external
configuration from the provisioning server.
Requires user role: ADMIN
Value space: <Internal/External/Auto>
Internal: Request internal configuration.
External: Request external configuration.
Auto: Automatically discover using NAPTR queries whether internal or external configurations
should be requested. If the NAPTR responses have the "e" flag, external configurations will be
requested. Otherwise internal configurations will be requested.
xConfiguration Provisioning Connectivity: Auto
Example:
It is possible to configure the codec (video system) using a provisioning system / an external
manager. This allows video conferencing network administrators to manage many video systems
simultaneously.
With this setting you choose which type of provisioning system to use. Provisioning can also be
switched off. Contact your provisioning system provider/representative for more information.
ADMIN
Requires user role:
<Off/TMS/VCS/CallWay/CUCM/Auto>
Value space:
Off: The video system will not be configured by a provisioning system.
TMS: The video system will be configured using TMS (Cisco TelePresence Management System).
VCS: The video system will be configured using VCS (Cisco TelePresence Video Communication
Server).
Callway: The video system will be configured using Callway (subscription service).
CUCM: The video system will be configured using CUCM (Cisco Unified Communications
Manager).
Auto: The provisioning server will automatically be selected by the video system.
Example: xConfiguration Provisioning Mode: TMS
This is the user name part of the credentials used to authenticate the video system with the
provisioning server. This setting must be used when required by the provisioning server. If
Provisioning Mode is Callway, enter the video number.
ADMIN
Requires user role:
<S: 0, 80>
Value space:
Format: String with a maximum of 80 characters.
Example: xConfiguration Provisioning LoginName: ""
