xStatus Video Layout Site [1..n] Output [1..5] GraphicName
Shows the name of the graphic layout. The name identifies the layout used right now at the specified
output.
NOTE: Note that while the FamilyName is constant as the long as the configurations on the system
does not change, the GraphicName varies depending on system state (the number of participants for
instance).
Value space of the result returned:
<S: 0, 100>
Example:
xStatus Video Layout Site 1 Output 1 GraphicName
*s Video Layout Site 1 Output 1 GraphicName: "full-pip"
** end
xStatus Video Layout Site [1..n] Output [1..5] GraphicNumber
Shows the number of the graphic layout. The number identifies the layout used right now at the
specified output.
Value space of the result returned:
<Integer value>
Example:
xStatus Video Layout Site 1 Output 1 GraphicNumber
*s Video Layout Site 1 Output 1 GraphicNumber: 1037
** end
xStatus Video Layout Site [1..n] Output [1..5] Descriptor
Shows the descriptor of the layout.
Value space of the result returned:
<Integer value>
Example:
xStatus Video Layout Site 1 Output 1 Descriptor
*s Video Layout Site 1 Output 1 Descriptor: 3
** end
xStatus Video Layout Site [1..n] Output [1..5] DescriptorOutput
Shows the descriptor output of the layout.
Value space of the result returned:
<Integer value>
Example:
xStatus Video Layout Site 1 Output 1 DescriptorOutput
*s Video Layout Site 1 Output 1 DescriptorOutput: 1
** end
