xCommand Camera ReconfigureCameraChain

Reinitialize the daisy chain of cameras and updates the CameraId parameter. The CameraId
parameter holds information of which camera is sitting in what position in the camera chain.
Requires user role: USER
Example:
xCommand Camera ReconfigureCameraChain
*r ReconfigureCameraChainResult (status=OK):
** end

xCommand Camera TriggerAutofocus

Trigger the autofocus functionality. The camera must support autofocus functionality. If the camera is
daisy chained, the CameraId is given by its place in the chain.
Requires user role: USER
Parameters:
CameraId(r): <1..7>
Example:
xCommand Camera TriggerAutofocus CameraId:1
OK
*r TriggerAutofocusResult (status=OK):
** end

xCommand Camera PositionActivateFromPreset

Selects pan, tilt, zoom and focus parameters for the given camera id from the selected preset.
CameraId: Give the camera id.
PresetId: Select preset 1 to 15.
USER
Requires user role:
Parameters:
CameraId(r): <1..7>
PresetId(r): <1..15>
Example:
xCommand Camera PositionActivateFromPreset CameraId:1 PresetID:1
OK
*r PositionActivateFromPresetResult (status=OK):
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

xCommand Camera Preset Activate

xCommand Camera Preset Edit

85
xCommand xCommand
This command activates a stored camera preset.
Note: The xCommand Camera Preset commands are used to store camera positions for individual
cameras. This is in contrast to the xCommand Preset commands where a single preset stores/
recalls ALL connected cameras plus the Video Input switcher settings. This makes it more usable for
integrations where one wants to store multiple camera positions individually per camera rather than a
complete camera position set.
PresetId: The preset number you want to activate.
Requires user role: USER
Parameters:
PresetId(r): <1..35>
Example:
xCommand Camera Preset Activate PresetId: 1
OK
*r CameraPresetActivateResult (status=OK)
** end
Edit a stored camera preset.
Note: The xCommand Camera Preset commands are used to store camera positions for individual
cameras. This is in contrast to the xCommand Preset commands where a single preset stores/
recalls ALL connected cameras plus the Video Input switcher settings. This makes it more usable for
integrations where one wants to store multiple camera positions individually per camera rather than a
complete camera position set.
PresetId: The preset number you want to edit.
ListPosition: The sort order position in the xCommand Camera Preset List result.
Name: The name of the preset in the xCommand Camera Preset List result.
Requires user role: USER
Parameters:
PresetId(r): <1..35>
ListPosition: <1..35>
Name: <S: 0, 255>
Example:
xCommand Camera Preset Edit PresetId: 1 ListPosition: 1 Name: ""
OK
*r CameraPresetEditResult (status=OK)
** end
