xConfiguration Video Output DVI [2, 4] Resolution

Select the preferred resolution for the monitor connected to the video output DVI-I connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640 _ 480 _ 60/800 _ 600 _ 60/1024 _ 768 _ 60/1280 _ 1024 _ 60/1280 _ 72
0 _ 50/1280 _ 720 _ 60/1920 _ 1080 _ 50/1920 _ 1080 _ 60/1280 _ 768 _ 60/1360 _ 768 _ 60/136
6 _ 768 _ 60/1600 _ 1200 _ 60/1920 _ 1200 _ 60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with the
connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
Example: xConfiguration Video Output DVI 2 Resolution: 1920 _ 1080 _ 60

xConfiguration Video Output Composite [5] MonitorRole

The Composite monitor role describes what video stream will be shown on the monitor connected to
the video output Composite connector. Applicable only if the monitor configuration is set to dual or
quadruple.
ADMIN
Requires user role:
<First/Second/PresentationOnly/Third/Fourth>
Value space:
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Third: Use for remote participants (only for quadruple monitor setup).
Fourth: Use for remote participants (only for quadruple monitor setup).
Example: xConfiguration Video Output Composite 5 MonitorRole: First

xConfiguration Video Output Composite [5] OverscanLevel

Some TVs or other monitors may not display the whole image sent out on the systems video output,
but cuts the outer parts of the image. In this case this setting can be used to let the system not use
the outer parts of video resolution. Both the video and the OSD menu will be scaled in this case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
xConfiguration Video Output Composite 5 OverscanLevel: None
Example:
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

xConfiguration Video Output Composite [5] Resolution

xConfiguration Video Selfview

xConfiguration Video WallPaper

64
xCommand
Select the preferred resolution for the monitor connected to the video output Composite connector.
This will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <PAL/NTSC>
Range: PAL, NTSC
xConfiguration Video Output Composite 5 Resolution: NTSC
Example:
Determine if the main video source (selfview) shall be displayed on screen.
Requires user role: USER
Value space: <On/Off>
On: Display selfview on screen.
Off: Do not display selfview on screen.
Example: xConfiguration Video Selfview: On
Determine if a background picture should be displayed on screen when idle.
Requires user role: USER
Value space: <None/Growing/Summersky/Custom/Waves>
None: No wallpaper will be displayed on screen.
Summersky, Growing, Waves: Select one of the predefined wallpapers to be displayed on
screen.
Custom: The custom wallpaper must be uploaded to the codec from the web interface before
selecting Custom. The maximum supported resolution is 1920x1280.
1) On the video system: Find the IP address of the codec. Open the menu on screen and go to
Home > Settings > System information to find the IP Address.
2) On your computer: Open a web browser and enter the IP address of the codec. Select
"Wallpaper" from the menu, browse for the file, and press the "Upload" button.
3) On the video system: Open the menu on screen and go to Home > Settings > Wallpaper >
Custom. Give it a few seconds to display the new picture. If the picture does not show, toggle
once between "None" and "Custom" wallpaper to make the change take effect.
Example: xConfiguration Video Wallpaper: Summersky
