xConfiguration Cameras Camera [1..7] Gamma Level
By setting the Gamma Level you can select which gamma correction table to use. This setting may
be useful in difficult lighting conditions, where changes to the brightness setting does not provide
satisfactory results. NOTE: Requires the Gamma Mode to be set to Manual.
Requires user role: ADMIN
Value space: <0..7>
Range: Select a value from 0 to 7.
xConfiguration Cameras Camera 1 Gamma Level: 0
Example:
xConfiguration Cameras Camera [1..7] IrSensor
The IR sensor LED is located in the front of the camera and flickers when the IR sensor is activated
from the remote control. Both the Codec C Series and PrecisionHD camera have IR sensors, and only
one of them needs to be enabled at the time.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the IR sensor on the camera.
Off: Disable the IR sensor on the camera.
Example: xConfiguration Cameras Camera 1 IrSensor: On
xConfiguration Cameras Camera [1..7] Mirror
With Mirror mode (horizontal flip) you can mirror the image on screen.
Requires user role: ADMIN
Value space: <Auto/On/Off>
Auto: When the camera is placed upside down the image is automatically mirrored. Use this
setting with cameras that can be mounted upside down, and that can auto detect that the camera
is mounted upside down.
On: See the selfview in mirror mode, e.g. the selfview is reversed and the experience of selfview
is as seeing yourself in a mirror.
Off: See the selfview in normal mode, e.g. the experience of selfview is as seeing yourself as
other people see you.
xConfiguration Cameras Camera 1 Mirror: Off
Example:
xConfiguration Cameras Camera [1..7] Whitebalance Mode
Set the camera whitebalance mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: The camera will continuously adjust the whitebalance depending on the camera view.
Manual: Enables manual control of the camera whitebalance, e.g. the level of the whitebalance
level setting will be used for the camera.
Example: xConfiguration Cameras Camera 1 Whitebalance Mode: Auto
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration
xConfiguration Cameras Camera [1..7] Whitebalance Level
xConfiguration Cameras Camera [1..7] DHCP
35
xCommand
Set the whitebalance level. NOTE: Requires the Camera Whitebalance Mode to be set to manual.
Requires user role: ADMIN
Value space: <1..16>
Range: Select a value from 1 to 16.
xConfiguration Cameras Camera 1 Whitebalance Level: 1
Example:
Applies to cameras which supports DHCP. The Cisco TelePresence PrecsisionHD 1080p camera
supports DHCP. The camera must be connected to a LAN. When set, the command enables support
for SW upgrade of daisy chained cameras. It will enable the camera's DHCP function and force
start of MAC and IP address retrieval. Remember to reset the DHCP when the camera is no longer
connected to a LAN.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable DHCP in the camera. The camera is automatically re-booted. After re-boot the DHCP
is started and the IP address will be retrieved. Run the commnand "xStatus Camera" for result.
Off: Disable DHCP in the camera. NOTE: This setting should be applied when the camera is not
connected to a LAN.
Example: xConfiguration Cameras Camera 1 DHCP: Off
