The Presentation commands

xCommand Presentation Start

Open a media stream from the selected presentation source.
PresentationSource: Select the video input source to be used for presentation.
Requires user role: USER
Parameters:
PresentationSource: <1..5>
Example:
xCommand Presentation Start PresentationSource:2
OK
*r PresentationStartResult (status=OK):
** end

xCommand Presentation Stop

Stop the media stream from the presentation source.
Requires user role: USER
Example:
xCommand Presentation Stop
OK
*r PresentationStopResult (status=OK):
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

The Preset commands

xCommand Preset Store

xCommand Preset Activate

97
xCommand xCommand
Store the connector selections for all video input sources and the current camera position for all
cameras. Note that all video input sources and all camera positions are included in each preset. The
system may hold 15 predefined video input presets.
PresetId: Select preset 1 to 15.
Type: Select Camera or All. Currently there is no difference if you select Camera or All.
Description: Enter a description of the camera preset.
Requires user role: USER
Parameters:
PresetId(r): <1..15>
Type(r): <All/Camera>
Description: <S: 0, 255>
Example:
xCommand Preset Store PresetId:3 Type:Camera Description:"Left view"
OK
*r PresetStoreResult (status=OK):
** end
Activate one of the local presets.
Requires user role: USER
Parameters:
PresetId(r): <1..15>
Example:
xCommand Preset Activate PresetId:3
OK
*r PresetActivateResult (status=OK):
** end
