2
2-8
5. Disconnect the power supply connector from the disk drive and the
internal SCSI cables of the I/O assembly from the disk drive.
See Figure 2-7.
6. Slide the disk drive assembly completely out of the DDP.
SCSI cables
Figure 2-7
Sliding the Disk Drive Assembly Out of the Chassis and
Disconnecting the Cabling
2 Gbyte Standard Connector Disk Drive Installation Manual—May 1995
Power supply
connector
