2
Opening and Closing the Desktop Disk Pack
2-2
Figure 2-1 shows major internal components of the Desktop Disk Pack.
Power supply
assembly
Disk drive
Figure 2-1
Components of the Desktop Disk Pack
1. Read the "Safety Agency Compliance" section in the Preface for safety
precautions.
2. Read Chapter 1 to determine which tools are required, how to shut down
the system, and how to verify jumper settings on the drive.
2 Gbyte Standard Connector Disk Drive Installation Manual—May 1995
Top cover
I/O assembly
Flex cable
Mounting plate
