Sun Microsystems 2.1 Gbyte 7200 rpm Installation Manual page 21

3 5 7 11 13 15
12 14
4 6 8 10 16
Figure 1-1 IBM Drive Jumper Settings
IBM Drive Jumper Descriptions
Table 1-1 lists the factory configured jumpers on the IBM drive. Table 1-2 lists
the SCSI target address settings.
Table 1-1 IBM Disk Drive Option Jumper Block
Description
(Reserved)
SCSI ID 2
SCSI ID 1
SCSI ID 0
Auto Start
Enable Active Termination
Master Sync
Slave Sync
External Acitivity LED
Before You Start
17 19 21 23 25 27 29
18 20 22 24 26 28 30
Jumper Pins:
1 and 2
3 and 4
5 and 6
7 and 8
11 and 12
13 and 14
(15)
(16)
17 and 18
1
31
32
Factory Set
yes
1-9
