Specifications - Cabletron Systems SmartSwitch 8000 Getting Started Manual

Chapter 1: Features Overview

Specifications

The SSR provides wire-speed switching and full non-blocking throughput. The hardware
provides wire-speed performance regardless of the performance monitoring, filtering, and
Quality of Service (QoS) features enabled by the software. You do not need to accept
performance compromises to run QoS or access control lists (ACLs).
The following table lists the basic hardware and software specifications for the SSR.
Feature
Throughput
Capacity
Routing
protocols
4
Specification
• 16-Gbps non-blocking switching fabric (SSR 8000)
• 32-Gbps non-blocking switching fabric (SSR 8600)
• Up to 30 million packets-per-second routing throughput (SSR
8600)
• Up to 15 million packets-per-second routing throughput (SSR
8000)
• Up to 250,000 routes
• Up to 2,000,000 Layer-4 application flows (SSR 8000)
• Up to 4,000,000 Layer-4 application flows (SSR 8600)
• 400,000 Layer-2 MAC addresses (SSR 8000)
• 800,000 Layer-2 MAC addresses (SSR 8600)
• 4,096 Virtual LANs (VLANs)
• 20,000 Layer-2 security and access-control filters
• 3 MB input/output buffering per Gigabit port
• 1 MB input/output buffering per 10/100 port
• 20 MB shared input/output buffering across WAN ports on a
WAN module
• 32 MB input/output buffering per Packet Over SONET/SDH
OC-3c port
• 64 MB input/output buffering per Packet Over SONET/SDH
OC-12c port
• IP: RIP v1/v2, OSPF, BGP 2, 3, 4
• IPX: RIP, SAP
• Multicast: IGMP, DVMRP
SSR 8000/8600 Getting Started Guide
