Figure 17
Cabling and Connector Specifications
The following table lists the media specifications for the 1000Base-LLX and 1000Base-LLX
(T-Series) line cards.
Port type
1000Base-LX
SSR 8000/8600 Getting Started Guide
shows the front panel of the 1000Base-LLX (T-Series) line card.
SRR-GLH39-02
1
Tx Link
Offline
Rx AN
Online
Gigabit Port
Figure 18. Front panel of 1000Base-LLX (T-Series) line card
Specification
• 802.3z standard (also uses 802.3x for flow control)
• SC-style Media Interface Connector (MIC); either connection pin
in the MIC can be used for transmit or receive; see
Line Card" on page 75
• 9.5 micron single-mode fiber-optic cable
• Maximum 70 kilometers (229,659 feet) segment length for 10
micron SMF fiber-optic cable
Chapter 1: Features Overview
1000BASE-LLX
2
Tx Link
Rx AN
Gigabit Port
for attaching cables
Hot
Swap
"1000Base-LX
