An alternate method of wiring the SSR 8600 power supply is to use a single set of wires (+
and -) from the DC source, and then tie the SSR 8600's wiring lugs together: + to + and - to
-. See Figure
SSR 8000/8600 Getting Started Guide
6 Gauge Wire
From - 48 Volt
source
6 Gauge Wire
From + 48 Volt
Source
Figure 32. Splitting each source wire to two 12 gauge wires
33.
To True
Ground
Figure 33. Tying SSR 8600 DC supply lugs together
Conductive
Splitter Block
12 Gauge Wire
12 Gauge Wire
Conductive
Splitter Block
12 Gauge Wire
12 Gauge Wire
Both positive (+) and both
negative (-) lugs are tied
together
From Power
From Power
Source
Source +
Chapter 2: Hardware Installation
SSR-16
Wiring Lugs
-
-
+
+
61
