Page 1: Installation Guide
™ 7C03 MMAC SmartSWITCH Installation Guide 9031699-01... - Page 2 The hardware, firmware, or software described in this manual is subject to change without notice. In no event shall Cabletron Systems be liable for any incidental, indirect, special, or consequential damages whatsoever (including but not limited to lost profits) arising out of or related to this...
-
Page 3: Fcc Notice
Notice FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Vcci Notice
Notice VCCI NOTICE This equipment is in the 1st Class Category (information equipment to be used in commercial and/or industrial areas) and conforms to the standards set by the Voluntary Control Council for Interference (VCCI) by Information Technology Equipment aimed at preventing radio interference in commercial and/or industrial areas. -
Page 5: Declaration Of Conformity
Manager of Engineering Services ___________________________________ Title Rochester, NH, USA ___________________________________ Location 89/336/EEC 73/23/EEC Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03886-5005 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England... -
Page 6: Table Of Contents
1.3.2 SmartSwitch interface modules ...1-4 1.3.3 Operations...1-5 1.4 RELATED MANUALS...1-6 1.5 GETTING HELP...1-6 CHAPTER 2 INSTALLATION 2.1 UNPACKING THE 7C03 MMAC SMARTSWITCH ...2-1 2.2 INSTALLING THE 7C03 MMAC SMARTSWITCH...2-2 CHAPTER 3 TECHNICAL SPECIFICATIONS 3.1 SERVICE...3-1 3.2 PHYSICAL ...3-1 3.2.1 Dimensions ...3-1 3.2.2 Weight ...3-1... -
Page 7: Chapter 1 Introduction
1.2 USING THE SMARTSWITCH MANUAL SET Each SmartSwitch interface module that can be inserted in the 7C03 MMAC SmartSwitch is shipped with a module user’s guide. For example, the 7E03-24 Ethernet SmartSwitch Interface Module User’s Guide explains the physical characteristics, specifications, and installation procedures of the 7E03-24 Module. -
Page 8: 7C03 Mmac Smartswitch Overview
The other two slots can support any combination of Ethernet, Token Ring, FDDI, and ATM SmartSwitch interface modules. Spanning the rear wall of the 7C03 MMAC SmartSwitch is the SmartSwitch Bus. All modules that are inserted into the 7C03 MMAC SmartSwitch connect to the SmartSwitch Bus. All communication between modules within the 7C03 MMAC SmartSwitch is achieved via the SmartSwitch Bus. - Page 9 P W R MAC ADR Figure 1-1. 7C03 MMAC SmartSwitch Because the 7C03 MMAC SmartSwitch does not attach to the data channels on the backplane of an MMAC chassis, data can not be transmitted internally from SmartSwitch interface modules to the other modules in the MMAC chassis.
-
Page 10: 7X00 Smartswitch Controller Module
1.3.1 7X00 SmartSwitch Controller Module The 7X00 SmartSwitch Controller Module is the only processing and management element in the 7C03 MMAC SmartSwitch. The 7X00 Module has no front panel data ports. All data enters and exits the 7X00 Module via the SmartSwitch Bus on the 7C03 MMAC SmartSwitch’s backplane. -
Page 11: Operations
Introduction 1.3.3 Operations Data packets entering through the front panel of a SmartSwitch interface module in the 7C03 MMAC SmartSwitch are converted by the module’s hardware into frames that have a common “canonical” format. Canonical frames are forwarded along the 7C03’s SmartSwitch Bus to the 7X00 Module in slot one. -
Page 12: Related Manuals
Appendices (module specific). Cabletron Systems 7X00 SmartSwitch Controller Module User’s Guide 1.5 GETTING HELP If you need additional support with the 7C03 MMAC SmartSwitch, or if you have any questions, comments or suggestions concerning this manual, contact Cabletron Systems Technical Support:... -
Page 13: Chapter 2 Installation
This chapter contains instructions for unpacking and installing the 7C03 MMAC SmartSwitch in an MMAC chassis. The 7C03 MMAC SmartSwitch can be installed in an MMAC-M5FNB or in an MMAC-M8FNB chassis. Because of the modular nature of the power supplies and interface... -
Page 14: Installing The 7C03 Mmac Smartswitch
3. Slide the 7C03 MMAC SmartSwitch straight into the chassis until the 7C03 engages the backplane connectors. 4. Tighten the top and bottom thumb screws on the 7C03 MMAC SmartSwitch. 5. You can now install the 7X00 Module and SmartSwitch interface modules into the 7C03 MMAC SmartSwitch. - Page 15 Installation card guide plastic rail Figure 2-1. Installing the 7C03 MMAC SmartSwitch in an MMAC-M8FNB...
-
Page 16: Chapter 3 Technical Specifications
TECHNICAL SPECIFICATIONS This chapter includes the technical specifications for Cabletron Systems 7C03 MMAC SmartSwitch. Cabletron Systems reserves the right to change these specifications at any time without notice. 3.1 SERVICE MTBF: MTTR: 3.2 PHYSICAL 3.2.1 Dimensions 33.1D x 29.2 H x 10 W centimeters (12.8 D x 9.0 H x 3.9 W inches)
