Cabletron Systems reserves the right to change specifications at any time
without notice.

A.1 OPERATING SPECIFICATIONS

Data Buffer Memory (RAM):
Internal Processor:
Controller:
Static RAM:
EEPROM:
FLASH memory:
CPU Memory:
Shared Memory:
Contact Cabletron Systems Technical Support as described in the Preface
for information on expanding FLASH, CPU, and Shared memory.
A.2 POWER SUPPLY SPECIFICATIONS
The MicroMMAC-T has a universal power supply which will
NOTE
accept input power between 100 and 250 Vac, 50/60 Hz.
The power supply has two outputs of +5 volts and +12 volts. Maximum
output power is 125 watts and the minimum efficiency is 65% under all
conditions of line at full load. The minimum and maximum load current
from each output is listed in
Output
+ 5 Volts
+12 Volts
APPENDIX A
SYSTEM SPECIFICATIONS
Table

Table A-1 Power Supply Outputs

Min. Load
1.00 Amps
0.15 Amps
8 MB (expandable, see Chapter 3)
Intel 80C960CF at 24 MHz
Texas Instruments TMS380C26
128 KB with battery back-up
128 KB
2 MB (expandable)
2 MB (expandable)
4 MB (expandable)
A-1.
Max. Load
15 Amps
4 Amps
Max. Power
75 Watts
48 Watts
A-1
