Chapter 2: Hardware Installation
ATM PHY Card
The following are instructions on how to attach cables to the various PHY interface cards
for the ATM line card.
APHY-67 and APHY-77
To attach the segment cables to your APHY-67 and APHY-77 card:
1. Align the transmit cable connector with the transmit port and the receive cable
connector with the receive port.
2. Push one connector into the PHY port and rotate clockwise 1/4 turn to lock it in place.
3. Repeat step 2 for the second cable.
APHY-82 and APHY-92
To attach the segment cables to your APHY-82 and APHY-92 card:
1. Align the key of the modular jack (MJ) plug with the locking key of the MJ receptacle.
2. Push the MJ plug into the receptacle until the plug mates fully with the locking key.
You will hear a snapping sound when the locking key engages.
APHY-21 and APHY-29IR
To attach the segment cables to your APHY-21 and APHY-29IR card:
1. Remove the dust caps from the PHY port and cable.
2. Line up the transmit cable connector with the transmit port and the receive cable
connector with the receive port. Insert the connectors, ensuring that the key is
correctly positioned
APHY-22
To attach the segment cables to your APHY-22 card:
1. Align the key of the modular jack (MJ) plug with the locking key of the MJ receptacle.
2. Push the MJ plug into the receptacle until the plug mates fully with the locking key.
You will hear a snapping sound when the locking key engages.
