Chapter 2: Installing and Removing the CPU and Memory
48
Figure 2-17 shows the four Octane2 DIMM banks, with two DIMM sockets in each bank.
System module
DIMM
sockets
Figure 2-17 Identifying DIMM Sockets and DIMM Banks
S1
S2
S3
S4
S5
S6
S7
S8
Heat sink
Banks
1
2
3
4
