Chapter 1: Getting Started
10
5. Connect the speaker/workstation cables (the cable with two connectors on each
end) to the active speaker, as shown in Figure 1-8.
The connectors cannot be installed incorrectly because they are different sizes:
male/male on one end, female/male on the other.
Connect the female connector to the power (middle) port on the back of the
right (active) speaker.
Connect its paired male connector to the R port on the back of the right (active)
speaker.
Speakers
Power
Right (active) speaker
Attaching the Speaker and Power Cable to the Active Speaker
Figure 1-8
Power
To left speaker
To speaker port
on workstation
