Chapter 1: Getting Started
12
7. Set up the microphone, as shown in Figure 1-10.
Place the microphone cord through the slot in the microphone base.
Slide the microphone back until it is firmly connected to its base.
Place the microphone and base on the center-top area of the monitor.
Place the microphone cable over the back of the monitor.
Attach the cable to the microphone port on your workstation.
Microphone
Attaching the Microphone
Figure 1-10
