Appendix B: Technical Specifications
224

Analog Line Level Port Pinout

The following diagram shows the pinouts for the analog audio ports and plugs.
Ground/return
Signal
Right
IN
OUT
Red
The following diagram shows the port (jack) pinout for the coaxial digital ports and
plugs.

Coaxial Digital Port Pinout

Ground/return
Signal
IN
Red
Coaxial digital has these features:
• Supports the AES3id professional format.
• Compatible with consumer formats including CP340, IEC958, and S/PDIF.
Ground/return
Signal
Left
White
Ground/return
Signal
OUT
White
