4. Replace the system drive, as follows:
Lift the handle.
With the handle fully extended, gently slide the drive into the drive bay, as
shown in Figure 7-17. The drive is connected to the frontplane when the front
edge of the drive is flush with the chassis.
Caution: Pushing in the system drive with force can damage the drive.
Option drive bays
System drive
Figure 7-17 Inserting the New Drive
Installing and Removing Internal Drives
175
