4. If your system has a lockbar installed remove it (a lockbar locks the system module
and bezel to the chassis).
Unlock the lock (see A in Figure 2-2) at the back of your workstation.
Pull the lockbar (B) out of your workstation.
A
Figure 2-2 Removing the Lockbar
B

Preparing the Workstation

33
