Appendix A
Technical Specifications

Digital I/O Performance Specifications

Digital I/O Performance Specifications Table
The following table provides digital input and output performance specifications for
the GoQAM.
Specification
Maximum Input Rate
Maximum Aggregate Output Rate
(including data insertion)
Maximum Total Sessions
Maximum Number of Sessions per Output
Maximum Number of PIDs per Session
Maximum Number of PIDs per Input
Transport
Maximum Number of PIDs for all Input
Transports
Maximum Packet Insertion Rate (for
externally sourced packets)
156
Value
216 Mbps for each of the four ASI input ports
39.104 Mbps for each of the RF output ports
(620 Mbps)
122
61 sessions per channel
16
8192, per MPEG spec
32K
500 Kbps maximum; 1 Kbps minimum
4004834 Rev D
