Basic operating concept

Examples of possible display formats

Depending on the operating state of your telephone set, the display has a different format.
Basic display format
Handset on-hook. Listening by loudspeaker/hands-free calling switched off. No connection establis-
hed. No call is signalled.
Examples of possible display formats in the basic state:
Quiescent display:
19.08.96 14:25
Calls: (3)ÁÁÁ˝
Messages:
Ø
VIP displayÁÁÁÁÁÁÁÁÁÁ
Tel. functionsÁÁÁÁÁÁÁ
Display format during programming
During programming you are in a menu or submenu.
Example of possible display formats during programming:
Settings
Time/dateÁÁÁÁÁÁÁÁÁÁÁ
LanguageÁÁÁÁÁÁÁÁÁÁÁÁ
Error toneÁÁÁÁÁÁÁÁÁÁ
MSN settingsÁÁÁÁÁÁÁÁ
Suppl. servicesÁÁÁÁÁ
MiscellaneousÁÁÁÁÁÁÁ
Connection state
A connection is being set up or a connection exists already.
Examples of possible display formats in the connection state:
Display format during
an incoming call:
Call: MSN A
01 123 45 67
to TADÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
rejectÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
forward (CD)ÁÁÁÁÁÁÁÁÁ
Date/Time
Caller list
no
Message on answ. machine
Cursor symbol
Other functions
that can be activated
Menu title
Submenu title
Called MSN
Caller's telephone number
Functions that
can be activated
VIP display:
19.08.96
›Feller ThomasÁÁÁÁÁÁ˝
CoiffeurÁÁÁÁÁÁÁÁÁÁÁ˝
Mustermann HansÁÁÁÁ˝
John MillerÁÁÁÁÁÁÁÁ˝
Tel. functionsÁÁÁÁÁÁÁ
Display format during
an outgoing call:
DM. 0.12
Í_ 01 765 43_ 21ÁÁÁÁÁÁ˝
_ _
Addl. connectionÁÁÁÁÁ
Tel. functionsÁÁÁÁÁÁÁ
9
14:25
Date/Time
Card file
entries assigned
to the VIP directory
Other functions that
can be activated
1'30" Call charges/duration
Telephone number
of called partner
Functions that
can be activated
