3Com Router 5000 and Router 6000 v2.41
Module Guide
Figure 3-1 Router 2-Port FXS/FXO/E&M MIM MOdule
II. Router 4-Port FXS/FXO/E&M MIM module
The appearance of Router 4-Port FXS/FXO/E&M is shown in the following figure:
Figure 3-2 Router 4-Port FXS/FXO/E&M

3.1.3 Interface Attributes

The interface attributes of FXS/FXO/E&M modules are given in the following table:
Table 3-1 Interface attributes of 2FXS/2FXO/2E&M and 4FXS/4FXO/4E&M and 8FXS
Attribute
Connector
Number of
connectors
Cable
Multifunctional Interface Modules (Router 5000)
RJ45
2 (Router 2-Port FXS/FXO/E&M
MIM module)
4 (Router 4-Port FXS/FXO/E&M
MIM module)
Telephone cable with ferrite core
E&M trunk (for E&M module, which should be made by users depending on
3-2
Description
