Step 5: Power on the router, and check the behavior of the LINK LED on the card
panel: OFF means fault occurs on the line and the signal is not synchronized. Check
the line status.
4.8 Router 4-Port CT1/PRI FIC and Router 4-Port Fractional
T1 FIC

4.8.1 Introduction

I. Router 4-Port CT1/PRI FIC
Router 4-Port CT1/PRI FIC, the 4-port channelized T1/PRI interface card, transmits,
receives, and processes T1 data traffic. In addition, you can use the card for other
purposes, such as CE1 access and the ISDN PRI function.
II. Router 4-Port Fractional T1 FIC
Router 4-Port Fractional T1 FIC, the 4-port fractional T1 interface card, differs from the
Router 4-Port CT1/PRI FIC primarily in the sense that:
The FT1 operating mode supported by the T1-F cards allows only one n x 64
kbps or n x 56 kbps bundle to be formed on each interface, where n = 1 to 24.
However, a T1 card allows arbitrary grouping of 24 channels and multiple
bundles.
The T1 cards do not support PRI mode.

4.8.2 Interface Attributes

The following table describes the interface attributes of the cards.
Table 4-17 Interface attributes of the cards
Attribute
Connector
Number of connectors
Interface standard
Interface rate
Cable type
Operating mode
Chapter 4 Flexible Interface Cards (Router 6000)
RJ-45
1
2
4
G.703/T1 102, G.704
1.544 Mbps
T1 cable (100-ohm straight-through shielded cable)
CT1, ISDN PRI (only supported by the cards)
FT1 (only supported by the cards)
4-28
