1.2.4 Interface attributes

The interfaces that the 3Com Router 3000 Ethernet Family provides are described as follows:
1.2.4.1 Console port
Table 1-3 Attributes of the console port
Attribute
Connector
Interface standard
Baud rate
Service
1.2.4.2 Ethernet interface
Table 1-4 Attributes of the Ethernet interface
Attribute
Connector
Interface type
Operating mode
RJ45
Asynchronous RS232
9600 (default) to 115200 bps
Connection to an ASCII terminal
Connection to the serial interface on a PC to run the terminal emulation
program on the PC
Command line interface (CLI)
10BASE-T
RJ45
MDI/MDIX autosensing
10 Mbps
Full duplex/half duplex
1-4
1. Product Overview
Description
10/100BASE-T
10/100 Mbps autosensing
Full duplex/half duplex
Supports only L2 switching
