3Com Router 5000 and Router 6000 v2.41
Module Guide
2) Connect one RJ45 connector of the Router 4-Port T1 IMA MIM conversion cable
to a peer device.
3) Check the status of the LINK LED on the panel of the Router 4-Port T1 IMA MIM
interface card. If the LED is off (indicating the line is faulty), check the line.

3.16 Router 1-Port CE3 MIM Module

3.16.1 Introduction

1-port channelized E3 interface module (Router 1-Port CE3 MIM) serves to:
Transmit/Receive and handle one channel of E3 fast traffic, as well as provide the
accessing of E3 traffic when working in E3 mode; and
Provide the low-speed accessing service at the speed of n x 64 kbps, where n is
smaller than or equal to 128, when working in CE3 mode.
Note:
E3 represents the tertiary group rate of E system in the TDM system, that is, 34.368Mbps. An E3
channel can be channelized into 16 E1 lines through the demultiplexing processes of E23 and E12, each
E1 line supporting both the operating modes of E1 and CE1. E23 is used to indicate either E2-to-E3
multiplex or E3-to-E2 demultiplex, and E12 to indicate E1-to-E2 multiplex or E2-to-E1 demultiplex. "E23"
and "E12" discussed here represent the demultiplex process.

3.16.2 Interface Attributes

The interface attributes of Router 1-Port CE3 MIM are given in the following table:
Table 3-38 Interface attributes of Router 1-Port CE3 MIM
Connector
Number of connectors
Interface standard
Interface rate
Interface cable type
Operating mode
Services supported
Attribute
SMB
2
G.703, G.704, G.751
34.368Mbps
E3 cable (75ohm coaxial cable)
E3
CE3
E3 leased line
Multifunctional Interface Modules (Router 5000)
Description
3-60
Chapter 3
