3.17.4 Interface Cable

Router 1-Port CT3 MIM and Router 1-Port CE3 MIM use the same type of interface
cables and make connection in the same way.

3.18 Router 1-Port 10/100/1000 MIM

3.18.1 Introduction

Router 1-Port 10/100/1000 MIM, the 1-port 10Base-T/100Base-TX/1000Base-T
Ethernet electrical interface card, is used for router-to-LAN communication.
The cards support:
100 meters (328.1 ft.) of transmission segment over the category-5 twisted-pair
cable.
Operation at 1000Mbps, 100Mbps, and 10Mbps, auto-sensing.
Half-duplex/full duplex, autonegotiation

3.18.2 Interface Attributes

The following table describes the interface attributes of the Router 1-Port 10/100/1000
MIM:
Table 3-42 Interface attributes of the Router 1-Port 10/100/1000 MIM
Attribute
Connector
Number of connectors
Interface type
Interface standard
Cable type
Operating mode
ON means the interface is in a loopback.
Blinking means an AIS, LFA, or RAI alarm signal is present.
OFF means no loopback or alarm is present.
Router 1-Port 10/100/1000 MIM
RJ-45
1
MDI/MDIX
802.3, 802.3u, and 802.3ab
Ethernet cable
10/100/1000 Mbps auto-sensing
Half-duplex/full duplex, autonegotiation
