Note:
Depending on how light travels, optical fibers are divided into multi-mode optical fiber and single-mode
optical fiber.
Single-mode optical fiber has very thin core, and transmits only in single mode on a
given wavelength. It features wide band and large transmission capacity.
Multi-mode optical fiber allows transmission in multiple modes on a given wavelength.
In multi-mode, lights in different modes travel at different speeds, resulting in phase
distortion and thus limiting the transmission band. In terms of fiber core size, there
are two types of multi-mode optical fibers: 62.5 μm and 50 μm, the transmission
media accepted by the ISO/IEC 11801 standard.

4.2.2 Interface Attributes

The following table describes the interface attributes of the Router 1-Port 100FX MM
FIC/100FX SM FIC.
Table 4-3 Router 1-Port 100FX MM FIC/100FX SM FIC interface attributes
Connector
Number of connectors
Optical fiber mode
Max. transmission segment
Central wavelength
Optical
transmitter
power
Receiver
sensitivity
Operating mode
Supported frame format
Attribute
SC
1
Single-mode
15 km (9.3 mi.)
1310nm (1261 to 1360nm)
Min. -15 dBm
Max. -8 dBm
Min. -31 dBm
Max. -8 dBm
Full duplex
100Mbps
Ethernet_II
Chapter 4 Flexible Interface Cards (Router 6000)
Description
100FX SM
Multi-mode
2 km (1.2 mi.)
1315nm (1270 to 1360 nm)
-20 dBm
-14 dBm
-31 dBm
-14 dBm
4-4
100FX MM
