Interface Leds - 3Com 3C13701 Module Manual

3Com Router 5000 and Router 6000 v2.41
Module Guide
Table 3-17 Interface attributes of the Router 2 AND 4-Port Enhanced Serial MIM
Attribute
Connector
Number of connectors
Interface standard and
operating mode
Min. baud rate(bps)
Max. baud rate(bps)
Cable
Supported service

3.7.3 Interface LEDs

The following figures show the 2 and 4-port panels:
Multifunctional Interface Modules (Router 5000)
Synchronous
DB-28
2 (FIC-2SAE)
4 (FIC-4SAE)
8 (FIC-8SAE)
V.24 V.35, RS449, X.21, RS530
DTE, DCE DTE
1200 1200
64 k 4.096 M
V.24 (RS232) DTE cable
V.24 (RS232) DCE cable
V.35 DTE cable
V.35 DCE cable
X.21 DTE cable
X.21 DCE cable
RS449 DTE cable
RS449 DCE cable
RS530 DTE cable
RS530 DCE cable
1) DDN leased line
2) Terminal access service
3-27
Description
Asynchronous
RS232
DCE
300
2.048 M 115.2
1) Dialup through modem
2) Backup
3) Asynchronous leased
line
4) Terminal access
service
Chapter 3
