3.4 NDEC Module

3.4.1 Introduction

Network Data Encryption Module (NDEC) supports IPSec protocol and speeds up the
encryption of IP packets by means of hardware, featuring high performance and high
reliability.
When NDEC module is inserted, the main board of the router handles IP packet
forwarding and implements the VPN with encryption features, and then the NDEC will
complete the task of encryption.

3.4.2 Appearance

The appearance of NDEC module is shown in the following figure.
Figure 3-20 NDEC

3.4.3 Interface Attributes

The interface attributes of NDEC are given in the following table:
Table 3-8 Interface attributes of NDEC
Protocol supported
The maximum number of concurrent IPSec
connections
Hardware algorithm
Attribute
3-15
Multifunctional Interface Modules (Router 5000)
Description
IPSec
100
1) Key algorithm (DES, 3DES, AES, QC5, Blowfish,
Cast-128, SkipJack)
2) Authentication algorithm (MD5, SHA-1 hash
algorithm)
