Field Definitions – Thermostat Screen (cont'd)
7 – Time
- Time of day displayed in Daylight Savings Time if chosen.
8 – Temperature Hold
- Holds current temperature indefinitely. The Hold button toggles between Hold and Return.
Pressing the Return button disables the hold feature and returns to the temperature settings
which are set in the schedule.
(See Day Class Settings in the TMI chapter)
9 – HVAC Activity
- Displays the current state of the HVAC system. For either Fuel Burner or Heat Pump the
following are displayed;
Heat
Aux Heat
Cool
10 – HVAC Mode Control
- Enables the HVAC Secondary Screen whereby HVAC and Fan settings can be modified. (See
HVAC Screen below)
11 – Next
- Displays of the next thermostat screen, either Status & Control Screen or the Sensor Satus
Screen if remote sensors are installed and enabled.
12 – Period State
- Displays the current scheduled Period. The four schedule Periods are "Morn"(ing), "Day",
"Eve"(ning) and "Sleep".
– Single stage heat is active.
- Auxiliary heat is active (Heat Pump).
- Single stage cooling is active.
