Intermec EasyCoder 201 II – Technical Manual
PAPER DIMENSIONS, cont'd.
Tickets with Black Mark
a
c
d
e
TICKETS
PAPER FEED
DIRECTION
1 /. The last third of a ticket or tag with
maximum length cannot be used for
printing! Also see "Max. printable
length".
NORMAL ROLL PRINTERS:
a Web Width:
Maximum .................................................. :
Minimum ................................................... :
b Copy Length:
Max. length (6 dots/mm)
Max. length (8 dots/mm)
Min. length (all) ......................................... :
b
Max. printable length (6 dots/mm) ............. :
Max. printable length (8 dots/mm) ............. :
c Black Mark Width:
Min. width ................................................. :
Max. width ................................................. :
The nominal detection point is 7 mm (0.28") from the inner edge of the web.
The black mark must be placed adjacent to the inner edge of the paper.
d Black Mark Height:
Commonly used height .............................. :
Minimum ................................................... :
e Black Mark Y-Position:
It is recommended to place the black mark as close to the front edge of the
ticket as possible and use a negative Stop Adjust value to control the paper
feed, so the tickets can be properly torn or cut off (see chapter "Setup
Parameters").
It is recommended not to allow possible perforation to break the edges of the
web. Else there is a small risk that the web may be partly separated before
printing, causing a paper jam.
Important!
Preprint that may interfere with the detection of the black mark should be
avoided. However, the LBLCOND statement allows the sensor to be
temporarily disabled during a certain amount of paper feed in order to avoid
unintentional detection, see Intermec Fingerprint Reference Manual.
The mark should be non-reflective carbon black on a whitish background.
89.0 mm
40.0 mm
1
........................... : 2475 mm
1
........................... : 1875 mm
15.0 mm
1650 mm
1250 mm
12.5 mm
(3.50")
(1.58")
(97.4")
(73.8")
(0.59")
(65.0")
(49.2")
10 mm (0.4")
no restriction
(0.5")
5.0 mm (0.2")
55
