Features

MULTI-FORMAT LVM SERIES UNIT HAS THE FOLLOWING FEATURES:
Compatible with varied SDI signals
- The product is compatible with varied SDI signals (408i, 576i, 720p, 1035i, 1080i, 1080p and 1080psf )
Compatible with varied analog signals
- The product is compatible with varied analog signals (Composite, S-Video, Component, RGB, etc.)
DVI Digital(HDCP) / Analog input support
- DVI digital/analog(VGA) input is available without any other accessory.
All-in-one type system
- Slim and all-in-one type monitor that requires no other accessories and optimized for space utilization.
Waveform/Vector Scope/Audio Level Meter support
- Waveform & Vector Scope (SDI input)
- Embedded Audio Level Meter
Audio in & out
- built-in internal speaker (Embedded audio & External audio in)
- Stereo audio out using phone jack & external audio in
Knob Control (LVM-172W)
- Easy to adjust user configuration using the control knobs.
BLUE ONLY/MONO/Focus-Assist
H/V delay
Wide variety of Markers & Safety Areas
- Center Marker, Safety Area Marker, Aspect Marker, Display Size(Scan)
1:1 SCAN
- Provides both full screen and unscaled native image.
Wide screen compatible
- Wide screen for 16:9 aspect ratio monitoring (LVM-172W)
- Wide screen for native 16:9 aspect ratio monitoring (LVM-242W)
AC/DC Compatible
- The product may be powered by normal AC source, but also capable with 12V/24V DC.
* LVM-172W : AC, DC12V/24V
* LVM-242W : AC, DC24V Only
Remote control function
- The product can be remotely controlled using external switch or RS-422 communication.
RS422/UMD feature support
- This product supports protocols provided by TVLogic or a TSL protocol.
Additional Features
- Wide Viewing Angle, Loop Through (SDI/Analog), VESA Mounting , 1000:1 Contrast ratio (LVM-242W), 900:1
Contrast ratio (LVM-172W), 350 cd/m2 brightness (LVM-172W), 400 cd/m2 brightness (LVM-242W), Easy to
operate OSD user interface, Rack Mountable design.
