Menu Organization & Adjustment
The product may be controlled and set system-wise through OSD displayed on the screen.
[1] Menu Organization
Below is the organization of the product's menu.
[2] Menu Control
You may control various functions using MENU, UP/DOWN and ENTER buttons on the bottom front of the
monitor.
[3] Menu Control Sequence
Menu control sequence follows the order below:
1. Press MENU button to bring the OSD menu on the screen.
2. Display the desired sub menu with the UP/DOWN button.
3. After selecting a sub menu, press ENTER to select an item with the UP/DOWN button.
4. Press ENTER to select the desired item (verified by highlighted field text turning red)
5. Press ENTER to save the new value after adjusting the value with UP/DOWN button. (Verified by
highlighted field returning to default black color)
6. Press MENU to remove OSD menu from the screen.
