Name & Function of Each Part
LVM-172W REAR
POWER S/W
AC IN
DC IN
LVM-242W REAR
FACTORY PGM
CVBS1/G/Y/S-Y
CVBS2/B/Pb/
CVBS3/R/Pr/S-C
DVI-I
SDI IN-A
SDI IN-B
SDI OUT
AUDIO OUT
AUDIO IN
REMOTE
RS422 OUT
RS422 IN
FACTORY PGM
CVBS1/G/Y/S-Y
CVBS2/B/Pb/
CVBS3/R/Pr/S-C
DVI-I
SDI IN-A
SDI IN-B
SDI OUT
AUDIO OUT
AUDIO IN
POWER S/W
AC IN
DC IN
REMOTE
RS422 OUT
RS422 IN
